Product Series: |
TUBULⒶRCH | SPEC GRADE |
|
Lamp Type: |
LED T8 Single & Double-Ended | Type B |
|
|
Base Type: |
G13 Bi-Pin | Use both shunted and non-shunted |
|
Wattage Equivalent: |
17W (2FT) | 25W (3FT) | 32W (4FT) | 59W (8FT) | |
||
CCT Options: |
3000K | 3500K | 4100K | 5000K |
||
Operating Temperature: |
-4°F to 113°F |
||
Regulatory: |
UL Damp Location |
||
QPL Rebate: |
DLC Standard |
||
Warranty1: |
7 Years | 50,000 Hours |
KEY FEATURES
✓ |
Full length glass lens with 320° light distribution |
✓ |
Instant-ON w/ No Visible Flicker |
✓ |
Uniform, end to end light output w/ zero pixelation |
✓ |
Universal Input Voltage: 120–277V |
✓ |
Simple Ballast Bypass, Easy Retrofit for Common Fluorescent Fixtures |
✓ |
Suitable for enclosed, dry and damp locations |
✓ |
Bypass (UL-B) may be single-ended or doubled-ended |
✓ |
All Glass Construction |
PERFORMANCE SUMMARY
MODELS |
LENGTH |
BARE WATT | LUMEN* |
CCT [xx] |
LISTING |
WARRANTY |
CTN QTY |
LT8F410xxDE5 |
4FT |
10W | 1900LM |
30-35-41-5000K |
UL | DLC |
7 Years - 50,000Hrs |
25 |
LT8F412xxDE5 |
4FT |
12W | 1800LM |
30-35-41-5000K |
UL | DLC |
7 Years - 50,000Hrs |
25 |
LT8F415xxDE5 |
4FT |
15W | 2000LM |
30-35-41-5000K |
UL | DLC |
7 Years - 50,000Hrs |
25 |
LT8F418xxDE5 |
4FT |
18W | 2300LM |
30-35-41-5000K |
UL | DLC |
7 Years - 50,000Hrs |
25 |
LT8F842xxDE5 |
8FT |
42W | 5550LM |
30-35-41-5000K |
UL | DLC |
7 Years - 50,000Hrs |
16 |
* NOTE: Please refer to PERFORMANCE SPECIFICATIONS for detailed performance. |
