LWPE-series

LWPE17-30-UD

For competitive quote, log in to the portal and request a Special Project Quote

Wattage

17W

25W

CCT

3000K

4000K

5000K

[{"id":39497272099009,"title":"17W \/ 3000K","option1":"17W","option2":"3000K","option3":null,"sku":"LWPE17-30-UD","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"LWPE-series - 17W \/ 3000K","public_title":"17W \/ 3000K","options":["17W","3000K"],"price":4300,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":null},{"id":39497272131777,"title":"17W \/ 4000K","option1":"17W","option2":"4000K","option3":null,"sku":"LWPE17-40-UD","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"LWPE-series - 17W \/ 4000K","public_title":"17W \/ 4000K","options":["17W","4000K"],"price":4300,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":null},{"id":39497272164545,"title":"17W \/ 5000K","option1":"17W","option2":"5000K","option3":null,"sku":"LWPE17-50-UD","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"LWPE-series - 17W \/ 5000K","public_title":"17W \/ 5000K","options":["17W","5000K"],"price":4300,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":null},{"id":39497272197313,"title":"25W \/ 3000K","option1":"25W","option2":"3000K","option3":null,"sku":"LWPE25-30-UD","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"LWPE-series - 25W \/ 3000K","public_title":"25W \/ 3000K","options":["25W","3000K"],"price":4400,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":null},{"id":39497272230081,"title":"25W \/ 4000K","option1":"25W","option2":"4000K","option3":null,"sku":"LWPE25-40-UD","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"LWPE-series - 25W \/ 4000K","public_title":"25W \/ 4000K","options":["25W","4000K"],"price":4400,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":null},{"id":39497272262849,"title":"25W \/ 5000K","option1":"25W","option2":"5000K","option3":null,"sku":"LWPE25-50-UD","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"LWPE-series - 25W \/ 5000K","public_title":"25W \/ 5000K","options":["25W","5000K"],"price":4400,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":null}]

The One to Replace All

Designed with a traditional look, this LED wall mount luminaire offers the shape you're accustomed to, combined with energy-efficient LEDs to provide high-powered illumination for your safety, security, or facility lighting needs.

Loading store locator from Stockist store locator...

Documentation Downloads

Quick Sheet

Installation Guide

Description
Specifications
Pricing & Availability

Description

APPLICATIONS

Hallways
Entryways
General Walkway
Security Lighting

Specifications

KEY SPECIFICATIONS

Housing: Die-Cast Aluminum
Operating Temp: -40°F — 130°F
Input Voltage: 120-277Vac
IP: UL Wet Location Listed
PF: >0.9 Non-Flicker
Efficacy: 110LM/W
THD: <20%
CRI: >70

Certifications

Model Specifications

Model	Watt (W)	Lens	Lumens (LM)	Voltage	CCT (K)
LWPE17	17W	Clear	1760LM 1800LM 1820LM	120-277V	3000K 4000K 5000K
LWPE17	17W	Frosted	1600LM 1700LM 1750LM	120-277V	3000K 4000K 5000K
LWPE25	25W	Clear	2500LM 2550LM 2600LM	120-277V	3000K 4000K 5000K
LWPE25	25W	Frosted	2550LM 2600LM 2700LM	120-277V	3000K 4000K 5000K

Pricing & Availability

For Sales Rep

The REP portal will enable sales reps to see pricing & availability:

Rep Portal

For Customers

The customer portal will only allow customers to see open orders, invoices and customer statements:

Customer Portal
