contrⒶLS · Bi-Level · Occupancy sensor
LDLL-E2/MSP /W
PIR occupancy sensor for the Eclipse-II downlight · 1-pin · IP65
PIR occupancy sensor in the Eclipse-II form factor. Plugs into a 1-pin audio-jack port, turns the light on with motion and off when the space empties. Range and hold time are set at the factory, so there is nothing to commission. Mounts up to 10 ft. Sealed lens, rated IP65 for damp locations.
Sensor
OCCUPIED
Light level
100%
Hold
—
Hold time is set at the factory; the light switches off after it.
Downloads
Documents & tools
Documents
- DatasheetLDLL-E2/MSP/WPDF ↓
- Quick SheetLDLL-E2/MSP/WPDF ↓
- Sell SheetLDLL-E2/MSP/WPDF ↓
- contrⒶLS Product GuideAll platforms · selection and orderingPDF ↓
Tools & support
Model specifications
LDLL-E2/MSP/W
Performance
| Detection | Passive infrared (PIR) |
|---|---|
| Max mounting height | 10 ft (3 m) |
| Detection range | Fixed |
| Hold time | Factory set |
| Stand-by dimming | Not applicable |
| Daylight harvesting | No |
Electrical
| Input voltage | 10–15 Vdc |
|---|---|
| Connector | 1-pin audio jack |
Installation
| Commissioning | None · factory set |
|---|---|
| Network | None · standalone |
Construction
| Rating | IP65 |
|---|---|
| Operating temp | −4 °F to 122 °F (−20 °C to 50 °C) |
| Finish | White |
Compliance
| Certification | UL Listed |
|---|---|
| DLC NLC | No · standalone sensor |
| Warranty | — |
How it works
Motion on, empty off. Nothing to set.
Occupied
On with motion
PIR sees movement and the light comes on.
Vacant
Off after the hold
After the factory-set hold time the light switches off. No stand-by level.
Set-up
Nothing to commission
Range and hold are fixed at the factory. No remote, no app.
Location
Damp-rated
Sealed optical lens, IP65.
Detection
Rated to 10 ft.
Mounting · side elevation, to scale10 ft max
Adjustable on sitestandalone
Detection range
FixedSet at the factory.
Hold time
FactorySet at the factory.
Stand-by
NoneSwitches on and off. No stand-by dimming.
Daylight
NoNo daylight harvesting.
Connector
1-pin audio jack
Plug-and-play 1-pin connection. 10–15 Vdc.
