PRODUCT OVERVIEW
* Options shown are pre-built in-stock items. We may install all available accessories prior to ship as part of our workbench assembly service.
* Options shown are pre-built in-stock items. We may install all available accessories prior to ship as part of our workbench assembly service.
Physical Features
*Note: The emergency battery is not available while the voltage is 347-480V
Ordering Guide
Model Series |
Watt (W) |
CCT (K) (XX) |
Gen Code |
Voltage |
Lens Model |
Option Code [a] |
Option Code [b] |
LLHB | LED Linear Highbay |
100 | 100W 130 | 130W 180 | 180W 210 | 210W 260 | 260W 360 | 360W 420 | 420W
|
40 | 4000K 50 | 5000K |
4 | 4rd Generation |
U | 120-277VAC H | 347-480VAC |
M |
Blank | None* EM08 | 8W Emergency Driver EM15 | 15W Emergency Driver |
Blank | None* MS20 | 20ft PIR Sensor MS40 | 40ft PIR Sensor |
Ordering Number Example
Model Series |
Watt (W) |
CCT (K) (XX) |
Gen Code |
Voltage |
Lens Model |
Option Code [a] |
Option Code [b] |
LLHB |
360 |
50 |
4 |
U |
M |
EM08 |
MS20 |
Model Specifications
Model |
Watt |
Voltage |
Lumens |
CCT |
LPW |
LLHB090* |
90W |
120-277Vac 347-480Vac |
12,200lm |
4000K (CRI80) 5000K (CRI80) |
136lm/W |
LLHB100* |
105W |
14,300lm |
136lm/W |
||
LLHB130** |
130W |
18,200lm |
140lm/W |
||
LLHB180* |
180W |
24,200lm |
134lm/W |
||
LLHB210** |
210W |
30,000lm |
143lm/W |
||
LLHB260** |
260W |
36,400lm |
140lm/W |
||
LLHB360* |
360W |
48,500lm |
135lm/W |
||
LLHB420** |
420W |
60,000lm |
143lm/W |
**DLC Premium | *DLC Standard
Sizing & Measurements
Model |
Width (in) |
Height (in) |
Depth (in) |
Weight (lb) |
LLHB090 |
13.3 |
12.6 |
2.0 |
3.94 |
LLHB100 |
12.3 |
12.6 |
2.0 |
3.94 |
LLHB130 |
12.3 |
12.6 |
2.0 |
3.97 |
LLHB180 |
20.7 |
12.4 |
2.0 |
6.90 |
LLHB210 |
20.7 |
12.4 |
2.0 |
6.96 |
LLHB260 |
24.6 |
12.6 |
3.0 |
8.14 |
LLHB360 |
41.3 |
12.4 |
3.0 |
14.32 |
LLHB420 |
41.3 |
12.4 |
3.0 |
14.42 |
